Search found 688 matches

by Forrest Chapman
Wed, Apr 04 2018, 1:19PM
Forum: eCabinet Systems Software
Topic: Dovetail drawer depth not resizing properly
Replies: 3
Views: 242

Re: Dovetail drawer depth not resizing properly

Thanks Clint, its weird that it happens after every beta test and not during. I looked back at my emails to Thermwood and found 3 other instances over the years where I have reported it, only the size differences were more dramatic then this time for me. This only happens when I resize the depth. I'...
by Forrest Chapman
Wed, Apr 04 2018, 12:44PM
Forum: eCabinet Systems Software
Topic: Dovetail drawer depth not resizing properly
Replies: 3
Views: 242

Re: Dovetail drawer depth not resizing properly

Follow up. I opened the job today to change one of the drawer sizes. I took the drawer from batch into cabinet editor and notice the depth was still off. However, when I change the width the depth corrected. I also tried just opening construction settings and clicking, it okay also fixed the depth. ...
by Forrest Chapman
Tue, Apr 03 2018, 2:57PM
Forum: eCabinet Systems Software
Topic: Dovetail drawer depth not resizing properly
Replies: 3
Views: 242

Dovetail drawer depth not resizing properly

This happens after every beta test. My dovetail drawer depth doesn't resize properly. This drawer is loaded into a cabinet with no parts and no insets so the cabinet size is the actual size of the drawer. When I resize it from 21" deep to 21.125" and hover over the drawer it says it's actu...
by Forrest Chapman
Tue, Apr 03 2018, 9:10AM
Forum: eCabinet Systems Software
Topic: Part Editor Cuts
Replies: 4
Views: 216

Re: Part Editor Cuts

Tom, make sure the profile is closed. Extend and cut all your line ends again or use the select chain option to find the break.

Forrest
by Forrest Chapman
Tue, Mar 20 2018, 1:05PM
Forum: eCabinet Systems Software
Topic: Edge Pull placement
Replies: 2
Views: 240

Re: Edge Pull placement

I was able to add some manually by way of Hardware Objects. Not the ideal way but with some extra work it got the job done.

Thanks, Forrest
by Forrest Chapman
Mon, Mar 19 2018, 10:39AM
Forum: eCabinet Systems Software
Topic: Edge Pull placement
Replies: 2
Views: 240

Edge Pull placement

Does anyone have an edge pull similar to Hafele HF12402310 that will place on the door properly? The supplied one sits on the surface instead of behind the edge.

Forrest
by Forrest Chapman
Sat, Mar 03 2018, 10:21AM
Forum: eCabinet Systems Software
Topic: Resizing Display Boards
Replies: 7
Views: 512

Re: Resizing Display Boards

To bad they can't be scaled like a display object. I would also like to see an option to lock them to a specific location (post on the corners) so when the cabinet is resized they move with it.

Forrest
by Forrest Chapman
Fri, Dec 15 2017, 5:26PM
Forum: Thermwood 3-Axis Machinery
Topic: THM Desktop on 10 year old machine
Replies: 11
Views: 956

Re: THM Desktop on 10 year old machine

It absolutely saves processing time. I have a 15 year old controller that runs code fine but gets bogged down when trying to nest large jobs. Plus you can process the next job while you're running a job. The other issue I started running into is finding printer drivers for new printers that work wit...
by Forrest Chapman
Fri, Dec 15 2017, 2:51PM
Forum: Thermwood 3-Axis Machinery
Topic: THM Desktop on 10 year old machine
Replies: 11
Views: 956

Re: THM Desktop on 10 year old machine

Hi David, I don't use the sync for various reasons. What I do is make all my tooling the max size at the desktop version. IE: the 3/8" compression for the outline tool is always set at .375". It can be whatever size under that it needs to be at the controller and offsets will compensate fo...
by Forrest Chapman
Tue, Nov 28 2017, 4:59PM
Forum: eCabinet Systems Software
Topic: Nesting discrepancy
Replies: 11
Views: 937

Re: Nesting discrepancy

Its always differed for me too. I think there are more factors involved when nesting in the control software like bit size with added clearance and however it handles spacing for secondary operations like tenons and dovetails. If you're doing flip ops first too it considers that on the edge of the s...
by Forrest Chapman
Tue, Oct 24 2017, 10:28AM
Forum: eCabinet Systems Software
Topic: Corner door sizes
Replies: 2
Views: 377

Re: Corner door sizes

Rachel, according to your reveal and gap settings the doors are coming out correctly. 292mm on the left door and 2- 296.5mm doors on the right side. Here is the math for the left hand door. Left Front cabinet dim is 315mm - 3mm left reveal= 312mm- 18mm right door thickness= 294mm- 2mm for the door t...
by Forrest Chapman
Mon, Oct 23 2017, 10:38AM
Forum: eCabinet Systems Software
Topic: Corner door sizes
Replies: 2
Views: 377

Re: Corner door sizes

Rachel, I assume you're in beta? Moderators might wanna move this to the beta forum so you can get help. Only beta users can open the file so I'll take a look while I'm here to see if I can figure out whats going on.

Forrest
by Forrest Chapman
Fri, Oct 20 2017, 2:54PM
Forum: eCabinet Systems Software
Topic: Frameless cabinet drawer slide installation
Replies: 2
Views: 452

Re: Frameless cabinet drawer slide installation

While in cabinet editor click the "Drawer Slides" tab and under the drawer slide selection there is a "Hole Pattern" drop down. Select "clear default" and it will remove it from the cabinet.

Forrest
by Forrest Chapman
Tue, Oct 10 2017, 7:38AM
Forum: eCabinet Systems Software
Topic: constraint deletes hole
Replies: 4
Views: 783

Re: constraint deletes hole

Marcel, my drawers are done this way too. Its possible you may have a graphics issue. If you rebuild the drawer after making the constraints does the hole show up?

Ian is correct too that it should be w/2.

Forrest
by Forrest Chapman
Tue, Sep 12 2017, 10:40AM
Forum: Thermwood 3-Axis Machinery
Topic: thermwood desktop ctr nesting scroll issue
Replies: 9
Views: 1606

Re: thermwood desktop ctr nesting scroll issue

Works for me!

Thanks, Forrest
